Tipo de rolamento: Two Ball Bearings
Material: Impeller &Frame: Fios de chumbo Plastic (UL94V-0)
Lead Wires: UL1007MENS35;AWG26
nbsp; .Red Wire Positive (+)
nbsp; .Fio preto negativo (negativo)一)
Peso: 5.0g
| MODEL | Bearing System | Rated Voltage | Operating Voltage Range | Input Current | Speed | Maximum Air Flow | Maximum Air Pressure | Noise |
| PART NO | B/S/F | VDE | VDE | AMP | RPM | CFM | MmH2O | Db-A |
| WSA03004_05L | B/S/F | 5 | 3.5~5.5 | 0.1 | 3000 | / | / | 25 |
| WSA03004_12L | B/S/F | 12 | 7.0~13.2 | 0.06 | 3000 | / | / | 25 |
| WSA03004_05M | B/S/F | 5 | 3.5~5.5 | 0.18 | 4000 | / | / | 27 |
| WSA03004_12M | B/S/F | 12 | 7.0~13.2 | 0.1 | 4000 | / | / | 27 |
| WSA03004_05H | B/S/F | 5 | 3.5~5.5 | 0.32 | 5000 | / | / | 30.5 |
| WSA03004_12H | B/S/F | 12 | 7.0~13.2 | 0.2 | 5000 | / | / | 30.5 |
| WSA03004_05U | B/S/F | 5 | 3.5~5.5 | 0.5 | 6000 | / | / | 34 |
