Tipo de rolamento: Two Ball Bearings
Material: Impeller &Frame: Fios de chumbo Plastic (UL94V-0)
Lead Wires: UL1007MENS35;AWG26
nbsp; .Red Wire Positive (+)
nbsp; .Fio preto negativo (negativo)一)
Peso: 44.g
| MODEL | Bearing System | Rated Voltage | Operating Voltage Range | Input Current | Speed | Maximum Air Flow | Maximum Air Pressure | Noise |
| PART NO | B/S/F | VDE | VDE | AMP | RPM | CFM | MmH2O | Db-A |
| WSA06015_12J | B/S | 12 | 7.0~13.2 | 0.1 | 3000 | 15 | 0.09 | 24 |
| WSA06015_12L | B/S | 12 | 7.0~13.2 | 0.12 | 3500 | 19 | 0.14 | 29 |
| WSA06015_24L | B/S | 24 | 14.0~26.4 | 0.06 | 3500 | 19 | 0.14 | 29 |
| WSA06015_12M | B/S | 12 | 7.0~13.2 | 0.14 | 4000 | 21.7 | 0.16 | 32 |
| WSA06015_24M | B/S | 24 | 14.0~26.4 | 0.08 | 4000 | 21.7 | 0.16 | 32 |
| WSA06015_12H | B/S | 12 | 7.0~13.2 | 0.18 | 4500 | 23.1 | 0.18 | 35 |
| WSA06015_24H | B/S | 24 | 14.0~26.4 | 0.1 | 4500 | 23.1 | 0.18 | 35 |
| WSA06015_12U | B/S | 12 | 7.0~13.2 | 0.26 | 5000 | 26.5 | 0.23 | 37 |
| WSA06015_24U | B/S | 24 | 14.0~26.4 | 0.11 | 5000 | 26.5 | 0.23 | 37 |
