Tipo de rolamento: Two Ball Bearings
Material: Impeller &Frame: Fios de chumbo Plastic (UL94V-0)
Lead Wires: UL1007MENS35;AWG26
nbsp; .Red Wire Positive (+)
nbsp; .Fio preto negativo (negativo)一)
Peso: 84.0g
| MODEL | Bearing System | Rated Voltage | Operating Voltage Range | Input Current | Speed | Maximum Air Flow | Maximum Air Pressure | Noise |
| PART NO | B/S/F | VDE | VDE | AMP | RPM | CFM | MmH2O | Db-A |
| WSA08018_12J | B/S/F | 12 | 7.0~13.2 | 0.14 | 1500 | 5.31 | 3.5 | 24.2 |
| WSA08018_12L | B/S/F | 12 | 7.0~13.2 | 0.18 | 2000 | 7.08 | 4.7 | 28 |
| WSA08018_24L | B/S/F | 24 | 14.0~26.4 | 0.1 | 2000 | 7.08 | 4.7 | 28 |
| WSA08018_12M, | B/S/F | 12 | 7.0~13.2 | 0.23 | 3000 | 10.63 | 7.1 | 32 |
| WSA08018_24M | B/S/F | 24 | 14.0~26.4 | 0.14 | 3000 | 10.63 | 7.1 | 32 |
| WSA08018_12H | B/S/F | 12 | 7.0~13.2 | 0.35 | 3500 | 12.4 | 8.3 | 38 |
| WSA08018_24H | B/S/F | 24 | 14.0~26.4 | 0.18 | 3500 | 12.4 | 8.3 | 38 |
